Toto Cradle Automated Lateral Patient Turning System
Contact Us To Learn More
Toto® Cradle automated lateral patient turning system enables prescribed lateral turning intervals, even when users are sleeping. The Toto Cradle provides consistent and controlled automated lateral patient turning intervals, supporting optimum (single-handed) care efficiency in a lightweight, user-friendly, and easy-to-set-up format.
Suitable for patients AT RISK to VERY HIGH RISK
For the treatment of all categories of pressure ulcers.
Swipe to view more images · Tap to zoom
Toto® Cradle - Care in motion
Automated lateral patient turning for enhanced care efficiency, comfort, and clinical outcomes
Toto Cradle automated lateral patient turning system enables prescribed lateral turning intervals, even when users are sleeping.
Toto Cradle provides consistent and controlled automated lateral patient turning intervals, supporting optimum (single-handed) care efficiency in a lightweight, user-friendly, and easy-to-set-up format.
It is designed to support the prevention and treatment of pressure ulcers as part of a package of care. It provides enhanced comfort and support, helping to improve patient concordance, particularly for individuals who require frequent repositioning or are less responsive to manual repositioning.
With a powered Toto Touch Control Unit and a turning platform fitted beneath the user's existing mattress, Toto Cradle automatically turns users at clinician-defined intervals from 30 minutes up to 4 hours, relieving pressure over their most vulnerable areas.
Optimising Care Efficiency and Supporting Caregivers
Reduces the need for manual repositioning, helping to relieve the strain on caregivers.
Enhances care efficiency, supporting single-handed care where appropriate.
Freeing up valuable time for improved patient care.
Enhancing Comfort, Wellbeing, and Patient Dignity
Minimises patient discomfort and pain associated with manual repositioning.
Preserves dignity and provides gentle, continuous repositioning for end-of-life and palliative care.
Promotes a sense of independence, safety, and stability, improving sleep quality and overall patient wellbeing.
Customisable Therapy for Personalised Care
User-determined side selection, inflation, and rest durations for personalised care.
Therapy Pause Mode allows care interventions without disrupting the automated therapy cycle.
Integrated alarms, alerts, and lockout functionality ensure therapy continuity and patient safety.
Supporting Improved Clinical Outcomes
Supporting pressure ulcer prevention and management aligned with international guidelines (EPUAP 2019).
Ensures effective and timely patient repositioning, reducing the risk of pressure damage.
Provides customisable prescribed turning intervals as part of a package of care.
Enhances comfort, increases patient concordance, and improves patient outcomes.
Effective Automated Pressure Redistribution
Continuously, consistently and effectively redistributes peak pressures from top-to-toe.
Unique 15-segment air cell design is compatible with any bed frame in any profiled position.
Specifically designed to work with alternating, hybrid, and high-specification foam mattresses.
Ensures seamless integration across acute and community settings.
A UNIQUE, LATERAL TURNING SYSTEM
- Clinically effective shown to redistribute pressure away from ‘at risk’ areas but also increases patient and staff compliance.
- Adaptive profiling platform designed for compatibility with any bed frame in any profiled or ‘rise and recline’ position.
- Quick and easy installation Weighing less than 6kg and delivered fully assembled in a transport bag.
- Promoting safety by removing the need for additional manual handling aids.
- Gentle, consistent and controlled turning fully supporting patients from head to toe.
- Ensuring compliance, ensuring patients are kept moving
- Toto Cradle Platform features a secondary tilt on the opposite side of the primary tilt, which work in parallel to cradle the user, providing enhanced comfort and support while minimising the risk of user migration across the support surface.
SPECIFICATION:
- Toto Cradle Platform Weight 8kg
- Maximum user weight 250kg
- Dimensions: L 1850mm W 745mm
- Order Code: Toto Touch Control unit – 4000000 • New Toto Cradle Platform 5100000
- NHS Supply Chain Code: Toto Touch Control unit – TLP85007 • New Toto Cradle Platform TLC85124
- Toto Cradle User guide: Please see download tab for instructions
- Suitable under any mattress except a domestic pocket sprung mattress
- Confirms to any profile
- Toto Cradle programmable automatically turns users at clinician-defined intervals from 30 minutes up to 4 hours
- Automated turning cycle with user-controlled tilt and rest times
- Very gentle lift to help with sleep disturbance
- Whisper-quiet operation (45db)
- Toto Touch Control Unit is compatible with Toto and Toto Cradle platforms
CONTENTS:
- 1 x Toto Touch Control Unit
- 1 x Control Unit power lead
- 1 x User guide
- 1 x Toto Cradle Platform including a fitted PU cover
- 1 x CPR deflation valve and tubing set
- 1 x Pair of air cells with quick connectors
- 1 x Platform Transport Bag
INDICATIONS FOR USE
The Toto Cradle lateral turning system is suitable for the prevention of pressure ulcers for the following patients:
- Identified as being at moderate to high risk of developing pressure ulcers
- Weighing up to 250kg (551lbs)
- Who are unable to change their position without assistance
- Identified as requiring regular turning and who are non-compliant with manual turning schedules
CONTRAINDICATIONS
- Do not use with patients with unstable spinal cord injuries or who are undergoing traction
- Do not use with patients with equilibrium disturbances
CONSIDERATIONS
- The use of bed rails should depend on the findings of an individual risk assessment. If the use of bed rails is deemed to be required, assess for the risk of entrapment. Always follow the manufacturer’s instructions.
- Assess for risk of entrapment.
VAT REFUNDS FOR DISABLED USERS
If you are chronically sick or disabled you may be eligible to claim back the VAT on your order.
QUICK GUIDE
Step 1: Place and complete your order.
Step 2: Download and complete the Eligibility Declaration Form.
Step 3: Send the completed form to Frontier Medical Group.
Step 4: If eligible we will refund the VAT to the card you used to process your Repose order.
To apply for VAT relief please complete your purchase and download the Eligibility Declaration Form. Please send the completed form to Frontier Medical Group. We will then process your application. If you are eligible for VAT relief we will refund the VAT to the card you used to process your order payment.
For further details please see our terms and conditions or visit the HMRC website.
Product Downloads
Toto Cradle Literature
Library of Evidence
